Optimising engine performance through turbocharger innovation

Two-stage turbocharging

Rolls-Royce is continuously advancing turbocharging technology through key innovations aimed at improving efficiency, performance, and environmental compliance. Among these developments are two-stage turbocharging and electrical turbocharging, both of which represent significant steps forward in engine optimisation.

Two-stage turbocharging involves using two turbochargers in series to compress air before it enters the combustion chamber. This approach ensures that sufficient air is supplied, even under conditions where backpressure from exhaust gas recirculation systems or the Miller process might otherwise compromise efficiency. Rolls-Royce’s two-stage turbocharging system is particularly compact, with axial air flow designs that are highly beneficial for marine engines. This innovation not only boosts performance but also aligns with stricter emissions regulations by supporting cleaner combustion.

Electrical turbocharging

Electrical turbocharging is another transformative development in the Rolls-Royce portfolio. It integrates an electric drive with the traditional turbocharger, which has effectively decoupled the turbocharger’s operating point from the diesel engine’s speed. This eliminates turbo lag, allowing for optimal performance across a range of operating conditions. Reducing turbo lag results in enhanced engine responsiveness, improves fuel efficiency, and reduces emissions.

Adapting to alternative fuels

As the global shift towards sustainable energy accelerates, Rolls-Royce is at the forefront of adapting its technologies to accommodate alternative fuels. These fuels, including methanol, hydrogen, and synthetic options, present new challenges for engine and turbocharger requirements. Its innovative approach ensures that its turbochargers remain compatible with these emerging fuel types.

“Rolls-Royce turbochargers are optimised to handle the demands of methanol”

Rolls-Royce is currently developing methanol engines based on its Series 4000 platform. Methanol, particularly green methanol produced from biogenic or renewable sources, is gaining traction as a CO2-neutral fuel option. Its high energy density and relatively simple storage requirements make it a practical choice for the marine and power generation sectors Rolls-Royce turbochargers are being optimised to handle the specific demands of methanol combustion, ensuring that performance and efficiency are not compromised.

Rolls-Royce is currently developing hydrogen combustion engines for stationary energy supply. The engine is intended to serve as a reliable and clean power source for gensets and combined heat and power plants, as part of the energy transition. Rolls-Royce has successfully tested a 12-cylinder gas version of the Series 4000 L64 engine with 100 % hydrogen. The tests showed very good characteristics in terms of performance, efficiency, and emissions.

Due to the different combustion behaviour of hydrogen compared to natural gas, some engine components, including fuel injection, turbocharging, piston design and control, were modified in the test engine. However, by building on proven technologies within the Power Systems’ portfolio, such as turbochargers, injection valves, and engine electronics and control, the development of the engine to use hydrogen was advanced quickly and efficiently.

The first installation running on 100% hydrogen is planned for early 2025 for the Enerport II lighthouse project in the German inland port of Duisburg, as part of the development of a CO2-neutral energy supply for a new container terminal.

Rolls-Royce has also started, with a consortium of five companies and research institutes, to develop the necessary technologies for a highly efficient first-of-a-kind hydrogen combustion engine to drive combined heat and power (CHP) systems. Under the Phoenix (Performance Hydrogen Engine for Industrial and X) project, funded by the German Government, the consortium aims to generate the same electrical and thermal energy (power density and efficiency) as is currently available through natural gas CHP units in the higher power range of up to 2.5 MW. When fuelled by green hydrogen, this next-generation stationary energy plant will be able to run in a CO2-free manner.

In addition to methanol and hydrogen, Rolls-Royce is continuously analysing the complete synthetic fuel production ecosystem, including Power-to-X. These fuels, such as e-hydrogen, e-methane, e-methanol and e-diesel are needed as well as biofuels to meet projected demand.

Hybrid and integrated propulsion systems, which combine traditional engines with electric drives and energy storage systems, are a key area of innovation for Rolls-Royce. These systems rely on efficient turbocharging to optimise the performance of internal combustion engines, particularly during dynamic load changes, and these turbochargers are integral to the success of hybrid systems, demonstrating their versatility and importance in modern propulsion solutions.

The integration of Rolls-Royce Turbochargers with hybrid systems has already shown promising results in the marine sector. For example, ferries operating in environmentally sensitive areas have benefited from hybrid systems powered by electric drives. These systems have significantly reduced emissions and fuel consumption, showcasing the potential of turbochargers to support sustainable solutions.

“Turbochargers are integral to the success of hybrid systems”

Rolls-Royce’s commitment to customer support extends throughout the lifecycle of its turbochargers. The company offers comprehensive service packages that include maintenance, repair, and retrofit solutions. A global network of service centres ensures rapid response times and minimises downtime for customers.

Digital monitoring tools enhance Rolls-Royce’s service capabilities by providing remote diagnostics and support. This approach reduces the need for on-site visits and allows operators to address potential issues quickly and efficiently. By prioritising customer satisfaction and operational commitment, customer support extends throughout the lifecycle of its turbochargers.

The company’s turbochargers exemplify the innovation and adaptability required to meet the evolving demands of industries facing environmental and operational challenges. By advancing turbocharging technology, integrating alternative fuels, and adopting digitalisation and AI it continues to set benchmarks for the future.

As industries worldwide transition towards a greener future, Rolls-Royce’s turbochargers remain a cornerstone of high-performance propulsion and power solutions. With a focus on alternative fuels, hybrid systems, and digital technologies, it is shaping the future of turbocharging while maintaining the highest standards of performance and environmental stewardship. Through continuous innovation and strategic partnerships, Rolls-Royce is poised to play a leading role in the global effort to achieve sustainability and energy efficiency.
